5000w baby fresnel

Designed for Quartz Tungsten-Halogen globes. More compact, lightweight aluminum housing with high performance. Front opening door, accessories fit in wide Diffuser Clips on front door with no light obstruction. Front and rear Molecool® T-Handles keyed to graduated to spot-to-flood scale. Molecool® locking knob on yoke. Spring loaded socket contacts for positive grip. Equipped with safety screen.

HEAD: Type 4191, 5,000 watts

RATING: 120/240 volts, A.C. or D.C., 41.6 amps max.—5,000 watts max. SOCKET: G38, Mogul Bipost. Spring loaded contacts.

SWITCH: 60 amp, 125 volt heavy duty, double pole. Mounted in trough. CABLE: Attached 3 ft., #6/1 Entertainment Cable with #10/1 ground
60 amp Bates and MC257G plug. (Specify type of plug when ordering).
Other wiring substitutes are available.

CONSTRUCTION: Aluminum with interlocking channels and perforated steel trough.

YOKE: Cast aluminum with removable 11/8″ steel yoke pin.

CONDENSER: 97/8″ dia. Fresnel of glass. 17° to 61° field angle.

MIRROR: Alzak Aluminum.

FOCUSING: Easy action Molecool® T-Handles. Front and rear.

FINISH: Clear Anodized Aluminum/Maroon Powder Coated Enamel.

SIZE: 16″ x 14″ x 17 1/4″.

HEAD WEIGHT: 333/4 lbs. (w/cable).
